Introduction
The Air Bubble Bag Machine is an automated packaging material production machine that specializes in manufacturing bubble cushion bags to effectively safeguard items from potential damage during transit. What sets this equipment apart is its exceptional versatility, enabling the production of bubble bags in a myriad of sizes and shapes. With a raw material unwinding width ranging from 10 to 1200 mm and an extrusion thickness of 50-180g/square meter, the worry of accommodating items of different sizes and shapes is eliminated. Simply adjust the specifications through the user-friendly control panel and effortlessly manufacture bubble cushion bags tailored to your specific needs.
Features
High degree of automation
The Air Bubble Bag Machine is a modern production line that employs advanced motion control and servo technology for automation. With the machine's help, manufacturing the bubble buffer bags has become an effortless process. The computerized system manages everything from unwinding the sheets to cutting, shaping, and conveying. All you need to do is set the production parameters, and the machine can speedily produce high-quality bubble bags without any disturbance.
One of the most notable features of this machine is its ability to determine and regulate the length and width of the raw materials. As a result, producing custom-sized bubble bags tailored to your product's needs is incredibly convenient. With all these exceptional features, the Air Bubble Bag Machine provides outstanding efficiency and productivity to your business.
High efficiency
The Air Bubble Bag Machine is a versatile equipment that can process various materials like HPDE, LLDPE, pearl film, and more. With just a single machine, users can efficiently perform multiple functions without the need for separate equipment. Additionally, thanks to the 110 KW power supply, this machine can achieve a maximum mechanical speed of 40m/min, resulting in exceptional production efficiency and significant cost savings.
High security
Our equipment is equipped with a static electricity remover to prevent adsorption between raw materials and bags. This helps in ensuring proper separation of bags and maintains their size and shape stability. Additionally, the equipment is designed with an alarm system that can issue warnings and initiate shutdown in case of any failures, thereby minimizing losses.
Mechanical performance parameters
| Scope of application: | There are a variety of different plastic materials commonly used in the manufacturing of different types of film products. For example, two popular types of resins used in film production are high density polyethylene (HDPE) and linear low density polyethylene (LLDPE). These resins provide different properties to the films, such as strength and flexibility. In addition to the resin type, there are also different types of film construction techniques used. Co-extrusion film is a popular method of layering multiple plastic resins to create a film with different properties in each layer. Pearl film is another option, which uses specialized additives to give the film a pearlescent appearance. Aluminized film is made by depositing a thin layer of aluminum onto one side of the film, which provides additional barrier properties to the film. In summary, film production involves a variety of materials and techniques to create films with different properties and functions. Understanding the different options available can help manufacturers select the best materials and methods for their specific applications. |
| The maximum width of raw material unwinding: | 1200mm |
| Maximum diameter of raw material unwinding: | 800mm |
| Maximum width of product winding: | 1200mm (standard width 10mm-1200mm adjustable) |
| Maximum diameter of product winding: | 1500mm |
| Maximum mechanical speed: | It should be noted that the speed of production, which can reach up to 40 meters per minute, is greatly influenced by various factors such as the materials used, production process requirements, and other conditions. |
| Maximum extrusion volume: | 300KG/h |
| Maximum extrusion thickness: | 180gsm |
| Minimum extrusion thickness: | 50gsm |
| Extrusion thickness uniformity: | 3% |
| Mechanical voltage: | 3-phase 4-wire, 380V, 50HZ |
| Power supply: | 110KW |
| Mechanical size: | 11mX5.5mX3.5m (LXWXH) |
| Mechanical weight: | 7000KG |
Raw materials of bubble film machine
HDPE, LDPE, LLDPE, 80% recycled material, pearlescent film/co-extruded film/aluminized film and other materials
Our mode of transportation
RFQ:
1. Is the device easy to install?
Yes. The installation is very convenient, and we can offer instructional video.
2. How long is the warranty period of the machine?
One year.
