Introduction
Introducing the Bubble Wrap Making Machine, a state-of-the-art packaging equipment designed for producing lightweight, durable, and shock-proof bubble film. This versatile machine caters to the needs of various industries, including express packaging, home furnishings, and electronic products. Its primary function is to heat and press polyethylene particles, transforming them into high-quality bubble wrap. With a maximum basic capacity of 200kg per hour and an impressive output of 30m/min, this machine guarantees exceptional efficiency.
What sets this Bubble Wrap Making Machine apart is its adaptability to users' preferences. It allows for flexible adjustments in bubble film diameter, film thickness, and other essential parameters. This feature empowers businesses to customize their packaging solutions according to specific requirements, making the equipment suitable for a wide range of applications. With its superior functionality and ability to produce top-notch bubble film, this machine is the perfect asset for any packaging operation.
Features
The Bubble Wrap Making Machine incorporates advanced motion control technology, enabling the computer to oversee every stage of production, from unwinding to cutting. This ensures a consistently high-quality bubble wrap that is both visually appealing and uniform. By synchronizing the manufacturing machine's speed with the winder's speed, this technology maintains a stable tension throughout the process. Consequently, issues like poor winding or overly tight bubble wrap, caused by excessive speed or sluggishness, are effectively prevented.
The automatic correction system is designed to identify and address any errors that may occur during the manufacturing process. By detecting issues such as offset and skew of the bubble film in real time, this system ensures that the products are of high quality and remain stable. Its ability to make timely corrections prevents any potential problems from arising.
Operating and maintaining the Bubble Wrap Making Machine is a breeze. This machine comes equipped with a user-friendly touch operation interface and a dependable fault detection system, capable of rapidly identifying and addressing any machine-related issues. With the straightforward control panel provided, operators can effortlessly regulate and inspect various production parameters to ensure optimal performance. The Bubble Wrap Making Machine is a prime example of equipment that is both effortless to operate and maintain, delivering exceptional results on every use.
The main technical parameters
| Scope of application: | The available materials for selection are LDPE with a melt flow index (MFI) range of 2.5-3.5, LLDPE with an MFI range of 2-3, or recycled LDPE material that can be used entirely. |
| Maximum width of the finished product winding: | 1200mm (Standard width adjustable 100mm-1200mm) |
| Maximum diameter of finished product winding: | 1500mm |
| Maximum mechanical speed: | （），30/。，。，，ChapGPT。 |
| Maximum extrusion capacity: | 200kg per hour |
| Maximum extrusion thickness: | 200gsm |
| Minimum extrusion thickness: | 25gsm |
| Extrusion thickness uniformity: | 3% |
| Mechanical voltage: | 3-phase 4-wire, 380V, 50HZ |
| Total power of power supply: | 60KW |
| Mechanical size: | 9mX2.8mX2.5m(LXWXH) |
| Machine weight: | 5000KG |
| Effective width of die head: | 1200mm |
| Extrusion screw diameter: | 65mm,65mm |
| Hard tooth surface reducer: | 146Type, 146Type |
| Motor power: | 18.5KW, 18.5KW |
| Inverter power: | 18.5KW, 18.5KW |
| Bubble roller diameter: | 240 |
