Introduction
Our state-of-the-art machine, the Bottom Seal Bag Making Machine, is specifically designed to produce high-quality bottom-sealed bags effortlessly. By automatically cutting the plastic film and creating a secure bottom seal, this machine streamlines the bag-making process with remarkable efficiency. With a maximum unwinding width of 1600mm and a maximum diameter of 1500mm, it caters to various bag sizes and specifications. Its utilization offers significant cost and time savings for production companies, ultimately boosting their profit margins and providing a competitive edge in the market. Experience the convenience and productivity advantages of our Bottom Seal Bag Making Machine.
Feature
High degree of automation
With the use of advanced numerical control system, the Bottom Seal Bag Making Machine is able to perform cutting, sealing, folding and other bag-making processes with ease. This machinery guarantees an effortless operation, as it reduces the need for additional manpower, thereby increasing production efficiency and minimizing labor intensity. All these features work together to ensure that the machine delivers a top-notch performance.
Fast production speed
Our ability to quickly produce a significant quantity of bags is a result of our exceptional production efficiency. With an impressive average production speed of 180 times per minute, we can easily meet the demands for bulk orders and high demand.
Low production cost
By utilizing our automated production products, we are able to significantly reduce the need for labor and bring down operational expenditures. Our innovative solutions surpass traditional bagging equipment, thereby lowering production expenses and nurturing our competitive edge in the market.
High production quality
With our state-of-the-art technology, our equipment boasts exceptional precision and automation, making it incredibly user-friendly and easy to operate. Our machines guarantee optimal bag-making accuracy, ensuring optimal sealing and reducing any potential quality issues resulting from improper use. As a result, our products are highly regarded for their consistent high quality.
Adaptable
Our production equipment is designed with a modular approach, allowing for the customization of different modules based on production requirements. This versatility enables us to cater to various materials, such as pearlescent film, bubble film, and composite bubble film rolls. By adapting our equipment, we ensure a seamless integration of these materials during the production process.
Mechanical performance parameters
| Scope of application: | Composite bubble film rolls, along with pearlescent film and other materials, are widely used in various industries. These materials offer exceptional protective packaging solutions with their unique properties and versatility. One of the key components in composite bubble film rolls is the pearlescent film. This film is characterized by its pearlescent appearance, which adds an elegant touch to the packaging. It is commonly used for gift packaging, food packaging, and electronic product packaging. The pearlescent film not only enhances the visual appeal but also provides durability and resistance against scratches and tears. Another important material in the composite bubble film rolls is the bubble film. This film is made up of tiny air-filled bubbles that absorb shocks and impact during transportation and handling. It acts as a cushioning material, protecting fragile and delicate items from damage. The bubble film is lightweight and flexible, making it easy to wrap around items of various sizes and shapes. The composite bubble film rolls are created by combining the pearlescent film with the bubble film. This combination offers the benefits of both materials, resulting in a high-performance protective packaging solution. The pearlescent film adds an aesthetic appeal, while the bubble film provides excellent cushioning and protection. These composite bubble film rolls are commonly used in industries such as e-commerce, electronics, cosmetics, and fragile item shipping. They ensure that products reach their destination in pristine condition, without any damage caused by external factors. In conclusion, composite bubble film rolls that incorporate pearlescent film and bubble film are versatile protective packaging materials. They offer a combination of aesthetics and functionality, making them an ideal choice for various industries. |
| Mechanical speed: | 180 beats per minute |
| Composite material unwinding maximum width: | 1600mm |
| Maximum diameter of composite material unwinding: | 800mm |
| The largest possible width for unwinding bubble film or composite bubble film material has been determined. This information can be used to ensure proper handling and utilization of these materials in various applications. | 1600mm |
| The biggest size possible for an unwinding bubble film or a composite bubble film material is determined by its diameter. To produce such a film, it must meet certain size specifications. It should be noted that the maximum size is crucial in terms of practical applications. Therefore, the diameter of the material must be taken into account during the production process. | 1500mm |
| One out of one bag maximum width: | 800mm (including envelope tongue) |
| One out of one bag maximum width: | 400mm (including envelope tongue) |
| Maximum length of bag making: | 600mm |
| Machine voltage: | 3-phase 4-wire, 380V, 50HZ, 16 square wires |
| Total machine power: | 60KW |
| Machine size: | 21000mmX1500mmX2300mm (LXWXH) |
| Mechanical weight: | 8500KG |
We will pay attention to every parts packing with bubble film or stretch film or wooden case.
Besides, we will load machines one by one carefully. And our delivery team is professional on all the machine inspection and certificates for your clearance custom
Our mode of transportation
FAQ
Q: Do you provide guarantee?
A: We provide one year warranty from the date the goods arrive at your factory. Any damaged parts, excluding personal reasons, will be provided free of charge.
Q: What transportation options are available?
A: The goods can be transported by sea or other means.
Q: What payment methods do you accept?
A: We accept payment via PayPal, Alipay, Credit Card, Western Union, Telegraphic Transfer (TT) and various other methods.
